QMW - Mirowave

Wavy glassless mirror panel

QMW - Mirowave The 00. iridescent colour has reflections ranging from aqua green to cobalt blue depending on the angle of incidence of the light.If observed from the front, the plates appear green, the more the viewing angle is lateral and the more blue they appear, the undulating surface obviously produces mixed effects.
View all
QMW - Mirowave Wavy reflections in the 00. iridescent and 95. anthracite colours.
QMW - Mirowave A plate of the color 00. iridescent, on the left, is reflected in a plate 95. anthracite, on the right.Notice how the reflection of the green plate turns blue due to the different incidence of light.And how the undulations of the plates deform the reflected subjects.
QMW - Mirowave mirror panels are semi-rigid and, within certain limits, unbreakable.
They have similar characteristics to QSR - Miroplan panels, from which they differ in the undulated surface obtained with thermoforming and in the consequent particular wavy and distorted reflection.
To protect the plates optimally during transport, the use of a special pallet with dimensions of 265 x 105 x h 15 cm is recommended.
Flame reaction
IFR - inherently flame retardant
FR certification
UNI 8177 class 2
DIN 4102 class B2
Composition
polystyrene base
metallized polyester surface
Weight
2,35 kg / m²
Thickness
2,0 mm
Dimensions
100 x 260 cm (dimensional tolerance -1‰ / +3‰)
Packing method
plate
Finish
mirror finish
matt black backside
Available colours
see colour chart
Custom colours
not available
Availabilty
full plates only

Colour chart

QMW - Mirowave 00. iridescent01. silver95. anthracite
