5LC - Professional C

Ecran motorizat lăţime 5 / 7 m

5LC - Professional C The counterweight bar disappears into the sturdy box that houses and protects the screen.
Vezi toate
Lățimi standard A - Ecran: 500 / 600 / 650 / 700 cmB - Cutie = A + 20 cmC - Contragreutate = A + 5 cm1 - Alimentare standard: în dreapta2 - Lower black band: h 10 cm
Raportul de aspect 4:3 - Dimensiuni standard Dimensiunea ecr. ... Greutate ±500 x h 375 cm ........... 90 kg600 x h 450 cm ..........110 kg650 x h 490 cm ......... 120 kg700 x h 525 cm ......... 130 kg
16:9 aspect ratio It is achieved by reducing the height of the screen 4:3 aspect ratio with the bottom limit switch.In the same way one can obtain other aspect ratios, for example the 16:10 aspect ratio and the 2.35:1 aspect ratio.
Installation to ceiling 5LC∙SS - Ceiling fixing bracketsA - M10 holeIncluded in the price:- No. 3 for screens up to 600 cm wide- No. 4 for wider screens
Wall installation 5LC∙SP - Wall fixing bracketsA - M10 holeB - M8 holeIn option with extra charge:- No. 3 for screens up to 600 cm wide- No. 4 for wider screen
Truss fixing 5LC∙TC - Truss fixing clampTube diameter from 48 to 51 mmIn option with extra charge:- No. 3 for screens up to 600 cm wide- No. 4 for wider screens
Normal endowment S - SwitchOptional 5TM∙2 - Radiocomanda with external receiver
5LC - Professional C, version protected by a solid and aesthetic box of the 5L - Professional screen, is a professional motorized screen which, in the largest version, reaches a width of 7 m.
It is employed to occasionally use public spaces mainly dedicated to the theater as a projection hall.
It is also ideal for medium-sized multifunctional rooms, such as classrooms, meeting rooms, conference rooms.
Structure
case din enameled alb aluminiu
winding roll din aluminum
Engine
silent engine 230 V - 50 Hz
power 40 Nm - consumption 322 W
speed 17 rpm - roll Ø 14 cm - lifting speed 9 cm per second
Radiocomanda (optional)
Ecran
at choice - conform Normei Europene EN 13501·1
Instalare
to ceiling / to wall / to the stage structures
Caracteristici
dimensiune personalizată prelucrarea too
maximum lăţime 7 m - maximum lifting height of the engine h 6,5 m
CE conformity

Lăţime of the ecran
h at choice
Greutate
the ecran is excluded
500 cm . . . . . . .
600 cm . . . . . . .
650 cm . . . . . . .
700 cm . . . . . . .
. 80 kg
. 95 kg
105 kg
110 kg

Total lăţime of the case
lăţime of the ecran + 20 cm

Graficul de culoare

Ecrane pentru proiecţie faţă PBO - Bianco OtticoPBL-BlackoutPBM-BlackoutMicroforatoPST-Stormy
Ecrane retroproiecţie RNV - NevadaRAR-Arizona
Film pentru chroma key QCK - Cychroma
